YETUO YTUP-60 Basic Ultrapure Water Machine
Model: YTUP-60
Product Overview:
The YETUO YTUP-60 Basic Ultrapure Water Machine features dual RO reverse osmosis water and UP ultrapure water outlets, with a water production capacity of 60 L/h at 25°C. UP water resistivity reaches 18.25 MΩ·cm, with total organic carbon (TOC) below 10 ppb. The system adopts a multi-stage PP+UDF+CTO+RO+DI+UP purification process and is equipped with LCD online water-quality monitoring, automatic alarms and automatic RO membrane flushing. It is suitable for laboratory applications including environmental analysis, physical and electrochemical research, high-precision instrument analysis, molecular biology, cell culture, protein purification and amino acid analysis.
- Product Details
- Product manual
YETUO YTUP-60 Basic Ultrapure Water Machine
Model: YTUP-60
Product Overview:
Suitable for environmental analysis experiments, physical and electrochemical research, interface studies, various high-precision instrument analyses, molecular biology and life sciences, in vitro fertilization, animal and plant cell culture, two-dimensional electrophoresis experiments, protein purification, amino acid analysis and genetic research.
Features of YETUO YTUP-60 Basic Ultrapure Water Machine
● Fully automatic pressure sensors and microcomputer control enable automatic purified water production. The user-friendly operation and display system is equipped with audible and visual alarm functions.
● The entire pipeline system adopts quick-connect fittings and comes standard with an external equipment water-supply outlet. External water storage tanks can be added, with various capacities available to meet different requirements.
● All pipelines are NSF-certified and adopt a modular quick-connect design, making installation and maintenance convenient.
● The system has low feed-water quality requirements. Its carefully designed pretreatment system can process different types of raw water from various regions.
● High water production capacity, long consumable service life and low operating costs.
● No-water alarm, full-tank alarm and ultrapure water quality alarm. The ultrapure water alarm threshold can be freely configured.
● A fully automatic RO membrane anti-scaling flushing program helps extend the service life of the RO membrane.
● Water-electricity separation, overcurrent protection devices, water-inlet protection and explosion-proof safety devices provide comprehensive protection during operation.
● A portable TDS test pen with a dry-battery power supply can measure the total dissolved solids (TDS) of tap water and RO water at any time, providing an approximate indication of conductivity.
● A high-brightness backlit LCD online monitoring instrument measures resistivity, conductivity, TDS and water temperature, with an accuracy of 0.01 MΩ·cm, enabling real-time monitoring of outlet water quality.
● Electronic-grade mixed-bed resin and a large-capacity purification tank help maintain stable water quality and a consistent water supply.
● An optional pharmaceutical-grade terminal capsule sterilizing filter is available to ensure sterile water quality.
Technical Specifications
| Parameter | Specification |
| Model | YTUP-60 |
| System Water Production Rate (25°C) | 60 L/h |
| System Process | PP+UDF+CTO+RO+DI+UP |
| Feed-Water Requirements | Municipal tap water, TDS <250 ppm, 5–45°C, 0.02–0.25 MPa, pH 3–10 |
| Purification System | |
| Pretreatment Unit | 10-inch PP Filter Cartridge ×1 + 10-inch Granular Activated Carbon Filter Cartridge ×1 + 10-inch Sintered Activated Carbon Filter Cartridge ×1 |
| RO Reverse Osmosis Unit | 400 GPD RO Reverse Osmosis Membrane ×1 |
| Post-Purification Unit | Large-Capacity Ultrapurification Column |
| UP Ultrapure Water Specifications | |
| Resistivity / Conductivity | 18.25 MΩ·cm at 25°C / 0.054 μS/cm at 25°C (<0.1 μS/cm) |
| Heavy Metal Ions | <0.1 ppb |
| Total Organic Carbon (TOC) | <10 ppb |
| Pyrogens / Endotoxins | - |
| Microorganisms / Bacteria | <1 CFU/mL |
| Ribonuclease (RNase) | - |
| Deoxyribonuclease (DNase) | - |
| Particles (>0.22 μm) | <1/mL |
| RO Reverse Osmosis Water Specifications | |
| TDS Value | RO Water TDS (Total Dissolved Solids, ppm) < Feed-Water TDS × 4% (Salt Rejection Rate >99%) |
| Divalent Ion Rejection Rate | 95%–99% (Using a New RO Membrane) |
| Organic Matter Rejection Rate | >99% when MW >200 Dalton |
| Particle and Bacterial Rejection Rate | >99% |
| Maximum RO Water Production Rate | 2.0 L/min (With Pressure Storage Tank Enabled) |
| Water Outlets and Monitoring | |
| Front Water Outlets | 2 Outlets: RO Reverse Osmosis Water and UP Ultrapure Water |
| Side Water Connections | Feed-Water Inlet, Pressure Tank Connection and Wastewater Outlet |
| Operating Pressure Monitoring | 0–1 MPa, 0–150 PSI |
| Water Quality Monitoring | TDS Test Pen + LCD Online Monitoring of Resistivity, Conductivity, TDS and Water Temperature |
| General Specifications | |
| Dimensions (L × W × H) | 44 × 45 × 46 cm |
| Power Supply | 220 V, 50 Hz |
| Power | 82 W |
| Weight | 32 kg |
| Standard Configuration | Main Unit with 1 Purification Column Set + TDS Test Pen + Accessory Kit + 3.2G External Water Storage Tank |
