YETUO YTLG-18E Vertical T-Shaped Rack Freeze Dryer

Model: YTLG-18E

Product Overview:

The YETUO YTLG-18E Vertical T-Shaped Rack Freeze Dryer features a compact, integrated structure designed for small laboratory applications. It adopts a T-shaped rack configuration with 16 branch pipes, a cold trap temperature of ≤-60°C and an ice collection capacity of 6 kg per batch. The equipment features a 7-inch color LCD touchscreen, automatic freeze-drying data storage and USB export, as well as cold trap sample pre-freezing, one-touch defrosting, vacuum alarms and fine vacuum adjustment.

Application Areas:

Physics, biology, medicine, chemistry, pathology, pharmacy, bacteriology, virology, zoology, forensic identification, food and health products, archaeology, printed materials and geology.

Product Features of YETUO YTLG-18E Vertical T-Shaped Rack Freeze Dryer

● Features a compact vertical integrated structure with a T-shaped rack configuration for laboratory freeze-drying applications.

● The cold trap features a gas-flow guidance structure designed to support water vapor collection, with uniform temperature distribution on the inner wall as described in the product specifications.

● The product page specifies a Danfoss compressor and a single-unit mixed-refrigerant refrigeration system. Actual supply configuration should be confirmed.

● The cold trap features an independent sample pre-freezing function for laboratory sample preparation.

● Equipped with a 7-inch color LCD touchscreen, user-friendly operating interface and screen-lock function. Mobile phone and computer remote control are available as optional configurations.

● The main display shows cold trap temperature, vacuum pressure, sample temperature and operating time. Operation permission management is provided for equipment settings.

● Supports data viewing, exporting and deletion. Freeze-drying data can be automatically saved and exported via USB.

● Supports freeze-drying applications using ampoules, penicillin vials, glass flasks, plasma bottles and trays.

● The cold trap features an independent sample pre-freezing function and one-touch defrosting.

● Built-in maintenance reminders help users keep track of equipment maintenance requirements.

● Vacuum alarm function provides alerts regarding vacuum conditions.

● Equipped with a high-precision vacuum valve for fine vacuum adjustment.

● Equipped with a corrosion-resistant stainless steel vacuum connection pipe and standard KF25 quick-connect clamps.

● The T-shaped rack configuration features 16 branch pipes.

Detailed Technical Specifications
