YETUO YTLG-18D Vertical Stoppering Multi-Manifold Freeze Dryer
Model: YTLG-18D
Product Overview:
The YETUO YTLG-18D Vertical Stoppering Multi-Manifold Freeze Dryer features a compact, integrated structure designed for laboratory sample freeze-drying. It provides a freeze-drying area of 0.12 m², a cold trap temperature of ≤-60°C and an ice collection capacity of 6 kg per batch. It is equipped with three Φ220 mm material trays, including a movable layer. The vial capacity is 880 vials for Φ12 mm, 465 vials for Φ16 mm and 240 vials for Φ22 mm. The equipment features a 7-inch color LCD touchscreen, automatic freeze-drying data storage and USB export, as well as cold trap sample pre-freezing, one-touch defrosting, vacuum alarms and fine vacuum adjustment.
Application Areas:
Physics, biology, medicine, chemistry, pathology, pharmacy, bacteriology, virology, zoology, forensic identification, food and health products, archaeology, printed materials and geology.
Product Features of YETUO YTLG-18D Vertical Stoppering Multi-Manifold Freeze Dryer
● Features a compact vertical integrated structure with a stoppering multi-manifold configuration for laboratory freeze-drying applications.
● The refrigeration system is designed for cold trap operation, with gas flow guidance technology to support water vapor collection.
● The product page specifies a Danfoss compressor. The actual compressor configuration should be confirmed before making brand-specific supply claims.
● The cold trap features an independent sample pre-freezing function for laboratory sample preparation.
● Equipped with a 7-inch color LCD touchscreen, user-friendly operating interface and screen-lock function. Mobile phone and computer remote control are available as optional configurations.
● The main display shows cold trap temperature, vacuum pressure, sample temperature and operating time. Operation permission management is provided for equipment settings.
● Supports data viewing, exporting and deletion. Freeze-drying data can be automatically saved and exported via USB.
● Supports freeze-drying applications using ampoules, penicillin vials, glass flasks, plasma bottles and trays.
● The cold trap features an independent sample pre-freezing function and one-touch defrosting.
● Built-in maintenance reminders help users keep track of equipment maintenance requirements.
● Vacuum alarm function provides alerts regarding vacuum conditions.
● Equipped with a high-precision vacuum valve for fine vacuum adjustment.
● Equipped with a corrosion-resistant stainless steel vacuum connection pipe and standard KF25 quick-connect clamps.
Detailed Technical Specifications
| Parameter | Specification |
| Model | YTLG-18D |
| Type | Stoppering Multi-Manifold Type |
| Freeze-Drying Area | 0.12 m² |
| Vial Capacity (Φ12 mm) | 880 vials |
| Vial Capacity (Φ16 mm) | 465 vials |
| Vial Capacity (Φ22 mm) | 240 vials |
| Cold Trap Temperature | ≤-60°C |
| Ice Collection Capacity | 6 kg/batch |
| Specified Vacuum Pressure | ≤5 Pa |
| Ultimate Vacuum Pressure | 2 Pa |
| Material Trays | 3 layers, Φ220 mm (including movable layer) |
| Cold Trap Dimensions | Φ280 × 350 mm (height) |
| Glass Cover Dimensions | Φ300 × 460 mm (height) |
| Main Unit Power | 680 W (standard vacuum pump: 550 W) |
| Main Unit Weight | 86 kg |
| Dimensions | 685 × 560 × 850 mm (excluding cover) |
| Power Supply | AC 220 V, 25 A, 50 Hz |
| Applicable Environment | Ambient temperature ≤30°C |
| Operating Noise | ≤60 dB |
| Standard Configuration | 1 vacuum pump, 2 KF25 clamps and 1 KF vacuum hose |
