YETUO SW-CJ-1D Clean Bench
Model: SW-CJ-1D
Product Overview
The SW-CJ-1D clean bench features vertical airflow and a working area measuring 700×490×540 mm (W×D×H). Its single-person, single-sided design is suitable for individual laboratory clean operations and routine experimental work. Consider the laboratory layout and experimental workflow when planning the installation.
When selecting a model, consider the intended operations, required working area, and laboratory layout. Confirm the equipment configuration according to the intended application.
Related model: SW-CJ-2FD Double-Person, Single-Sided Clean Bench.
- Product Details
- Product manual
YETUO SW-CJ-1D Clean Bench — Product Details
The SW-CJ-1D features vertical airflow and a single-person, single-sided operator arrangement. Its working area measures 700×490×540 mm (W × D × H).
The work surface is made of stainless steel. Before selection, check the working space required by your equipment, the installation location and the intended workflow.
Technical Specifications
| Parameter | SW-CJ-1D |
|---|---|
| Model | SW-CJ-1D |
| Colony count | ≤0.5 colonies per dish per hour (Φ90 mm culture dish) |
| Average air velocity | 0.25–0.45 m/s (two-speed adjustment) |
| Noise level | ≤62 dB(A) |
| Vibration half-amplitude | ≤0.5 μm (X, Y and Z directions) |
| Illuminance | ≥300 lx |
| Power supply | Single-phase AC 220 V, 50 Hz |
| Weight | 85 kg |
| HEPA filter dimensions and quantity | 695×460×38 mm; quantity: 1 |
| Fluorescent / UV lamp rating and quantity | Fluorescent: 15 W × 1; UV: 15 W × 1 |
| Operator arrangement | Single-person, single-sided |
| Working area (W × D × H), mm | 700×490×540 |
| Overall dimensions (W × D × H), mm | 850×580×1600 |
Working-area dimensions and overall dimensions describe different parts of the equipment. Confirm the installation space and required configuration before ordering.
Related model: YETUO SW-CJ-2FD Clean Bench.
