YETUO YTLG-10CN-80 Benchtop Manifold Freeze Dryer

Model: YTLG-10CN-80

Product Overview:

The YETUO YTLG-10CN-80 Benchtop Manifold Freeze Dryer is designed for laboratory sample freeze-drying and scientific research. Featuring a compact benchtop structure and a manifold drying assembly, it supports compatible external freeze-drying containers for different sample preparation requirements. The standard model provides a freeze-drying area of 0.12 m², a cold trap temperature of -80°C (no-load, at an ambient temperature of ≤28°C), an ice collection capacity of 3 kg per batch, a specified vacuum pressure of ≤5 Pa (no-load), and an ultimate vacuum pressure of 2 Pa. It includes four Φ200 mm material trays with 70 mm spacing. The main unit weighs 50 kg (excluding chamber cover accessories) and measures 440 × 550 × 490 mm (excluding the drying chamber cover).

Freeze-Drying Principle:

Freeze-drying is a drying process based on sublimation. Materials are first frozen and then placed under suitable vacuum conditions, allowing ice to sublimate directly into water vapor. This process is used in laboratory sample preparation and preservation applications. The final characteristics of freeze-dried materials depend on sample properties and processing conditions.

Product Features:

1. Features a compact benchtop structure with a manifold drying assembly for laboratory freeze-drying applications.

2. Equipped with a branded compressor for the refrigeration system.

3. The cold trap features an independent sample pre-freezing function for laboratory sample preparation.

4. Equipped with a 7-inch color LCD touchscreen featuring a user-friendly operating interface and screen-lock function. Remote control via mobile phone or computer is available as an optional configuration.

5. The main display shows cold trap temperature, vacuum pressure, sample temperature and operating time. Operation permission management helps reduce accidental setting changes.

6. Supports real-time curve viewing, data review, export and deletion. Freeze-drying data can be automatically saved and exported via USB.

7. Supports freeze-drying applications using ampoules, penicillin vials, glass flasks, plasma bottles and trays.

8. The cold trap provides an independent sample pre-freezing function and one-touch defrosting.

9. Built-in maintenance reminders help users keep track of equipment maintenance requirements.

10. Vacuum alarm function provides alerts regarding vacuum conditions.

11. Equipped with a quick air intake connector for convenient sample removal after freeze-drying.

12. Equipped with a chamber locking function and password-based unlocking management to help prevent accidental operation.
