YETUO YTLG-10AN-80 Benchtop Standard Freeze Dryer
Model: YTLG-10AN-80
Product Overview:
The YETUO YTLG-10AN-80 is a benchtop standard freeze dryer with a freeze-drying area of 0.12 m², a cold trap temperature of -80°C under no-load conditions at an ambient temperature of ≤28°C, and an ice collection capacity of 3 kg per batch. It is equipped with four Φ200 mm material trays with a layer spacing of 70 mm. The vial capacity is 920 vials for Φ12 mm, 480 vials for Φ16 mm and 260 vials for Φ22 mm. The equipment features a 7-inch color LCD touchscreen, real-time curve viewing, automatic freeze-drying data storage and USB export, as well as sample pre-freezing, one-touch defrosting, vacuum alarms, quick air intake and password management.
- Product Details
- Product manual
YETUO YTLG-10AN-80 Benchtop Standard Freeze Dryer
Model: YTLG-10AN-80
Product Overview:
The YETUO YTLG-10AN-80 is a benchtop standard freeze dryer designed for laboratory sample preparation. Freeze-drying uses the principle of sublimation to remove water from frozen materials under vacuum conditions. The material remains frozen during the drying process, helping preserve its structure. The unit provides a freeze-drying area of 0.12 m², a cold trap temperature of -80°C under no-load conditions at an ambient temperature of ≤28°C, and an ice collection capacity of 3 kg per batch. It is equipped with four Φ200 mm material trays with a layer spacing of 70 mm. The vial capacity is 920 vials for Φ12 mm, 480 vials for Φ16 mm and 260 vials for Φ22 mm.
Product Features:
1. The cold trap features rapid refrigeration and uniform inner-wall temperature. Professional gas-flow guidance technology is used to support water vapor collection.
2. Equipped with an internationally branded compressor and single-unit mixed-refrigerant refrigeration technology.
3. The cold trap is equipped with a sample pre-freezing function, providing a pre-freezing option for laboratory sample preparation.
4. Equipped with a 7-inch color LCD touchscreen, a user-friendly interface and a screen-lock function. Remote control via mobile phone and computer is available as an optional configuration.
5. The main display shows cold trap temperature, vacuum level, sample temperature and operating time. Operation permission management helps prevent incorrect operation.
6. Supports real-time curve viewing, data viewing, exporting and deletion. Freeze-drying data can be automatically saved and exported via USB.
7. Supports freeze-drying applications using ampoules, vials, glass flasks, plasma bottles and trays.
8. The cold trap provides an independent sample pre-freezing function and one-touch defrosting.
9. Built-in maintenance reminders help users keep track of equipment maintenance.
10. Equipped with a vacuum alarm to notify users of abnormal vacuum conditions.
11. A quick air-intake connector allows convenient sample removal after freeze-drying.
12. Equipped with a chamber locking function and password management to help prevent accidental operation.
Detailed Technical Specifications:
| Parameter | Specification |
| Model | YTLG-10AN-80 |
| Type | Standard Type |
| Freeze-Drying Area | 0.12 m² |
| Vial Capacity (Φ12 mm) | 920 vials |
| Vial Capacity (Φ16 mm) | 480 vials |
| Vial Capacity (Φ22 mm) | 260 vials |
| Cold Trap Temperature | -80°C (no-load, ambient temperature ≤28°C) |
| Ice Collection Capacity | 3 kg/batch |
| Standard Vacuum Degree | ≤5 Pa (no-load) |
| Ultimate Vacuum Degree | 2 Pa |
| Material Trays | 4 layers, Φ200 mm |
| Layer Spacing | 70 mm |
| Overall Power | 1050 W total; standard vacuum pump: 370 W (-80°C) |
| Main Unit Weight | 50 kg (cover accessories excluded, -80°C) |
| Main Unit Dimensions | 440 × 550 × 490 mm (excluding freeze-drying cover) |
| Operating Noise | ≤55 dB |
| Power Supply | AC 220 V, 50 Hz / Optional 110 V, 50 Hz |
| Vacuum Pump | Standard 2XZ-2 vacuum pump / Optional imported vacuum pump |
